Atlas Ultraviolet UV LED 3/8 in - 7L/min System
Atlas Ultraviolet UV LED 3/8 in - 7L/min System
SKU:
- Free shipping when you spend over £70 (incl. VAT).
Couldn't load pickup availability
The Atlas LED UV 7 LPM delivers powerful, chemical-free UV-C sterilisation in a compact, intelligent design. Engineered to eliminate up to 99.9% of E. Coli and harmful microorganisms at flow rates up to 7 LPM, it provides reliable point-of-use water disinfection without affecting taste, odour, or water temperature.
Featuring built-in flow activation technology, the unit automatically operates only when water is flowing, helping to maximise efficiency and extend the 3,000-hour LED service life. The integrated LED status indicator provides clear visual feedback on system operation and end-of-life status for simple maintenance monitoring.
Constructed from durable polypropylene and aluminium alloy with an IPX7 waterproof rating, the Atlas LED UV 7 LPM is ideal for reverse osmosis systems, drinking water dispensers, and compact filtration installations where dependable microbiological protection is essential.
| Main Material | PP, Aluminium alloy |
| Electrical Supply | 100V–240V 50/60Hz |
| Output Voltage | 24 Vdc 1A |
| Power | 10.5 W |
| Working Temperature | 2°C – 65°C |
| Pressure | 0.8 MPa |
| Connections | 3/8” |
| Working Flow of Filtered Water (10 Microns) | 3–5 L/min |
| Working Flow of Osmosed Water | 7 L/min |
| Minimum Flow Required for Activation | 0.5 L/min |
| Sterilisation Rate | 99.9% (E. Coli) @ 7 LPM |
| Service Life | 3,000 hours |
| Waterproof Grade | x7 |
Built-in flow switch
It is activated when water flows and deactivated when water flow stops.
Does not heat the water.
Built-in LED status control.
For installations with 1/4” pipe, ask for the 3/8” - 1/4” reduction (Ref. 951014).
